Tecnografica Coachella Decorative Panels
COACHELLA DECORATIVE PANELS
COACHELLA DECORATIVE PANELS
Code 81012
A single slab can reach a size of 150×300 cm and can be entirely decorated and customized, following the specific characteristics of your own project.
INFORMATION
BRAND
Tecnografica
PRODUCT TYPE
Decorative Panels
PRODUCTION
Made in Italy
TEMPERATURE RANGE
-20°C +80°C
MAXIMUM SIZE
148x300 cm
DIMENSIONAL TOLERANCE
± 1.5 mm
TOLERANCE OF ORTHOGONALITY
<4 mm
THERMAL CONDUCTIVITY
5.5 W/m²K
MATERIAL
Laminated Glass
THERMAL EXPANSION
8 ∙10-6 °C-1
THICKNESS
8.7 mm
WEIGHT
21 kg/m2
SURFACE HARDNESS (MOHS SCALE)
5.5
RESISTANCE
Impact Resistance Uni En 12600 : 1(B)1
BURNING BEHAVIOR
B-s1, d0 according to UNI EN 13501-1
FEATURES
-Large Format -Laminated Glass Decorative Panel -Which Can Be Backlit.
APPLICATIONS
-Walls -Wet Environments
-Furniture -Interior Doors
-Kitchens -Sinks -Tubs
DOWNLOADS
↓ Data sheet
↓ Complete Form
MAIN CHARACTERISTICS
- Highly aesthetic image effect and depth, thanks to images being scanned with the Superscan HD system.
- Possibility of customizing the design and measurements.
- Safety glass.
- High impact resistance.
- Large-format ceramic slabs installation method.
- Workable on site.
- Also available in tempered glass version.
FINISHES
ECO FINISH
Eco is a cellulose fiber-based finish, pvc-free, with no chemical solvents and vinyl glues. It is an ecological, certified, and embossed finish with stucco effect. As for all the other finishes, also on eco the image quality is very high, and the colors are bright. This is the right finish for people who want to decorate their home, having special consideration for the environment.
METAL FINISH
Metal is the vinyl wallpaper with metallic effect by tecnografica. Thanks to the silver foil that covers the whole surface, when the light hits the wallpaper, it returns incredible iridescent reflections. Metal wallpaper enhances metal colors such as gold, silver, and copper, and gives particular brilliance to vibrant, saturated colors. Moreover, the special embossing with fabric effect makes this finish very elegant and suitable for every environment, both residential and commercial.
H20 FINISH
H2O is the fiberglass waterproof wallpaper, which can be installed in bathrooms and in all environments characterized by a high rate of humidity. The peculiar weave of this fiberglass finish ensures an excellent definition and vividness of printing, as for the other finishes of the catalogue. Thanks to H2O, it is possible to install the wallpaper in environments in which there is a direct contact with water, such as the internal part of the showers or close to bathtub.
VINYL WALLPAPERS (TNT)
This woven non-woven finish is characterized by a spatulate effect on the surface. TNT is part of the vinyl technical wallpapers, which allow the reproduction of bright colors and unique details. The three-dimensional effect of this finish gives depth and texture to designs, enhancing the high resolution of the digital printing.
VINYL WALLPAPERS (FABRIC)
The peculiarity of Fabric is the structured fabric effect surface. The elegant and regular texture makes it one of the most appreciated finishes for Art Collections designs. Fabric is one of the technical vinyl wallpapers, able to guarantee the reproduction of fine details and of every shade of color.
