ROLLER BLIND

ROLLER BLINDS

Ann Idstein has a special relationship to this simple, yet clever product. Next to the Venetian Blinds, the Roller Blinds were the foundation upon which the company’s original collection was built. More than 60 years later, it still holds a special place within the product range.

The design principle of the Roller Blind is quite simple and well proven. Fabric rolled on an aluminium tube is pulled up and down by the use of a bead chain, spring mechanism or motor. Two clear benefits of the roller design is that the product is very compact when rolled up and it makes it possible to cover a large window pane with an even textile surface within seconds.

Fabrics range from transparent- to black out and there are numerous types of fittings and extras that can add an individual touch to the product. Wooden slats from our Venetian Blind collection can also be used as design element at the bottom of the fabric, creating contrast or matching the fabric.

Depending on the width of the Roller Blind, the tube diameter is changed in order to guarantee stability. Smaller blinds rely on a 30mm tube, whereas the widest sizes are produced with an 80mm tube. Larger blinds are supplied with a power transmission, making them easy to control despite their size.

INFORMATION

BRAND

Ann Idstein

PRODUCT TYPE

Roller Blind

MATERIAL

- Wood
- Fabric
- Aluminium

MICRO-USB

Micro-USB charger for 230V socket

WALL FITTED

Optionally, a wall fitted 1-channel radio switch is offered.

ELECTRICAL CABLE

Electrical cable can be placed left or right.

FABRIC CONTROL CORD

- Colour as roller blind
- Length can be decided
- Ring: white, chrome, brass

MOTOR IS AVAILABLE

230 V motor is available for types M & L, with or without radio control.

MAINTAIN

Easy to maintain

ENVIRONMENT

Indoor

CHAIN CONTROL

Plastic chains are available in white, light grey, beige and black. Endless loops are offered for control lengths: 500, 750, 1000, 1250, 1500, 1750, 2000 & 2250 mm. Other lengths with chain connector. Metal chain at additional cost. Childsafe chain stretcher can be added.

COLLECTION

Roller

PRODUCTION

Made in Sweden

DOWNLOADS

↓ Brochure
↓ Material
↓ How To Measure

COLORS

-Plastic fitting covers (standard)
-Metal fitting covers (additional cost)

FITTING & DIMENSIONS

MOUNTING PROFILE

Colour : white, black or anodized alu.

- For type S: B 44 x H 56 mm
- For type M: B 61 x H 78 mm

CASSETTE

Colour : white, black or anodized alu.

- For type S: B 71 x H 73 mm
- For type M: B 90 x H 90 mm
- For type L: B 121 x H 120 mm

UNIVERSAL FITTINGS

An overview of the colours (fitting covers) on offer can be found below

- Type S : B 43 mm | H 56 mm | D 22 mm
- Type M : B 62 mm | H 78 mm | D 29 mm
- Type L : B 86 mm | H 108 mm | D 44 mm

COLORS

METAL FITTING COVERS (ADDITIONAL COST)

-Alu White -Stainless -Alu Grey

PLASTIC FITTING COVERS (STANDARD
